Heritage – Dawlish Dual Control Recessed Valve With Twin Integral Stopcocks – Chrome

The luxury traditional Dawlish dual control concealed thermostatic shower valve with twin integral stopcocks, manufactured from brass with a  polished chrome finish, Heritage’s elegant range of shower valves are precision engineered to provide a luxury showering experience. The shower valves are thermostatic so the water stays a consistent temperature even if the water pressure fluctuates. Quality assured by a 5 year guarantee.

Suitable for two outlets.

Product Details

• Product Code: SDA05
• Finish: Chrome
• Product Type: Traditional
• Construction: Body is of brass construction & is designed to conform to BS EN 2000
• Valve Type: Ceramic Disc Valve
• Supply: Suitable for all plumbing systems, preferably balanced. The inlet hot water temperature must be at least 10% above the required blend temperature
• Inlet Connections: 15mm Compression connections
• Working Pressures: Min 0.2bar, Max 5.0bar
• Chrome plated to BS EN 248
• Suitable for cavities between 45-75mm
• Minimum cold water supply temperature is 5ºC
• Maximum hot water supply temperature is 80ºC
• Flow rate at 0.2bar (open outlet without flow regulators) is 9LPM from stopcock. 12.9LPM from both outlets together.
• Cartridge serviceable from the front
• Manufactured to comply with WRAS


Concealed valve with integral diverter which allows use with both a fixed head and flexible handset.

Guarantee – 5 years covering manufacturing faults.

Flow Rates

0.2 Bar – (Handset) 6.04 l/m
0.5 Bar – (Handset) 9.55 l/m
1.0 Bar – (Handset) 13.51 l/m
2.0 Bar – (Handset) 19.1 l/m
3.0 Bar – (Handset) 23.4 l/m
5.0 Bar – (Handset) 30.2 l/m
